JBL LSR 305 MK II
Original 100%
Garansi Resmi 1 Tahun PT. IMS
Powered 5″ Two-Way Studio Monitor
The next-generation JBL 305P MkII compact powered studio monitor makes legendary JBL performance available to every studio. With the revolutionary JBL Image Control Waveguide and refined transducers JBL 305P MkII offers stunning detail precise imaging a wide sweet spot and impressive dynamic range that enhances the critical listening capabilities of any modern workspace. Featuring patented technologies derived from the JBL 7 Series and M2 Master Reference Monitors and sporting a sleek modern design JBL 305P MkII delivers outstanding performance and an enjoyable mix experience at an accessible price.
Features
- Patented Image Control Waveguide for detailed imaging and a broad room-friendly sweet spot
- Next-generation JBL transducers for optimized transient response and improved linearity
- Patented Slip Stream low-frequency port for superior bass performance at all playback levels
- Dual integrated custom Class-D amplifiers provide 82 watts of power for high output and dynamic range
- New Boundary EQ settings compensate for low frequency variants introduced by the environment
- HF Trim switch adjusts high-frequency output to room acoustics or personal preferences
- Flexible connectivity with balanced XLR and 1/4″ TRS inputs +4dBu / -10dBV input-sensitivity switch and adjustable volume control
- Engineered to JBL Linear Spatial Reference design criteria for outstanding accuracy in any working space
- Strenuous JBL 100-hour full-power test ensures years of reliability
- Sleek modern design provides a visual upgrade to any studio
Specifications
LF Driver : 126mm (5″)
HF DRIVER SIZE : 25mm (1″)
HF DRIVER TYPE : Soft dome
Crossover : 1725Hz 4th order acoustic Linkwitz-Riley
OK FOR USE NEAR MAGNETICALLY SENSITIVE EQUIPMENT
INPUT SENSITIVITY (-10dBV INPUT) : 92dB / 1m
Power Configuration : Bi-amplified
HF DRIVER POWER AMP : 41W Class-D
LF Driver Power Handling : 41W Class-D
Frequency Response ( 3 dB) : 49Hz 20kHz
Frequency Range (-10dB) : 43Hz 24kHz
LOW FREQUENCY EXTENSION (-10dB) : 43Hz
Maximum Continuous SPL : 94dB
Maximum Peak SPL : 108dB
MAXIMUM PEAK INPUT LEVEL(-10dBV / +4dBu) : +6dBV / +20.3dBu
SYSTEM DISTORTION CRITERIA :
ELECTRICAL DISTORTION CRITERIA : 0.2% THD @ 1kHz / 2.83VRMS output;
Signal to Noise Ratio: 75dBA (A-Weighted) 70dBr (unweighted) relative to 2.83VRMS output
Coverage Angle : 120 x 90
Input Connectors1 x XLR female 1 x TRS female balanced
HF TRIM CONTROL :-2dB 0dB +2dB
BOUNDARY EQ : LF Shelf @ 50Hz: -3dB -1.5dB 0dB
AC INPUT VOLTAGE : 100 240VAC ( 10%) 50 / 60Hz
ENCLOSURE TYPE : Ported
Enclosure : 15mm MDF
Enclosure Finish : Matte black PVC
BAFFLE CONSTRUCTION : Injection-molded structural ABS
CABINET DIMENSIONS (H x W x D) : 298 x 185 x 231 mm (11.75″ x 7.3″ x 9.9″)
DISPLAY CARTON (H x W x D) : 354 x 244 x 299mm (13.9″ x 9.6″ x 11.8″)
SHIPPING CARTON (H x W x D) : 373 x 260 x 315mm (14.7″ x 10.2″ x 12.4″)
Net Weight (each) : 4.73 kg (10.43 lbs)
SHIPPING GROSS WEIGHT : 5.72 kg (12.61 lbs)
Harga Per Set / Sepasang
