JBL KX 180 Professional-Grade Digital Processor
Original 100%
Garansii resmi 1 tahun PT IMS
KX180 is a professional-grade digital processor designed for karaoke applications and provides a full set of audio processing for enhancing or fine-tuning music and voice. KX180 is equipped with three 6.5mm connectors for microphone input two groups of RCA connectors and an optical connector for music input and one pair of RCA connectors for recording out. It supports storage and recall of up to 10 presets and manual or auto control of Dance or Sing mode.
Features
Two groups of microphone inputs
15-band PEQ and compressor for each Mic Input
Three levels of Feedback Inhibition for each Mic Input
Independent control of Echo and Reverberation
Two pairs of RCA connectors and an Optical connector for Music Input
15-band PEQ for Music Input
Three levels of Excitement for Music Input
Six output channels: Right Left Centre Sub Surround Right and Surround Left.
10-band PEQ for Right and Left Outputs
7-band PEQ for Surround and Centre Outputs
5-band PEQ for Subwoofer Output
Compressor provided for each output channel
Two independent REC channels can be paired into stereo
Authority control for front panel controls
Up to 10 presets can be saved
Specifications
Mic Input Type 3 x 1/4 unbalanced
Impedance 7.5K Ohms
Level Control ? to +0.8dBu
Line Input Type RCA unbalanced left & right
XLR Output Type Unbalanced
Level 0dBu Nominal +14.2dBu Maximum
RCA Output Type Unbalanced left & right
Frequency Response 20Hz~20KHz ? 1.0dB
THD+N
Dynamic Range >100dB
A/D Conversion 24bit 48KHz
DSP Processor High performance 32-bit/40-bit floating-point processor
Carrier Frequency 38KHz
Format NEC
Distance Device dependent
Angle Device dependent
Computer Connection USB 2.0
AC Power Supply AC 220V/50Hz
Dimensions (W X D X H) 485 X 205 X 47mm
Net Weight 2.8Kg
Gross Weight 3.47Kg
