JBL Control 25 AV
Garansi Resmi 1 Tahun PT. IMS
Shielded Indoor/Outdoor Monitor Speaker
The Control 25AV utilizes a deep cabinet high power components and complex network to achieve extremely smooth high fidelity performance from a compact 2-way loudspeaker. Premium performance capability and even coverage ensures excellent sound quality throughout the listening area. Magnetic shielding allows use of the speaker in close proximity to video monitors. The top-quality transformer with reduced saturation allows use on either 70 volt or 100 volt distributed speaker lines with similar performance fidelity. In the bypass position the high 8 impedance allows use of more speakers on a loudspeaker line. The unique global patent pending InvisiBall mounting method is simple to install aims easily and provides a high degree of theft deterrence. The cabinet accepts a variety of paints to match any d cor. Weather resistance is maximized by a stainless steel grille which is paintable. Coating the woofer in polypropylene and terminating its circumference in JBL s WeatherEdgeTM a seamless butyl rubber extension of the woofer surround protects critical transducer elements. The polycarbonate tweeter diaphragm is reinforced with a thin film of titanium for added rigidity and endurance. Nickel/zinc rust-resistant terminals ensure a secure input connection. JBL s exclusive SonicGuard overload protection is virtually inaudible to the listener ensuring reliability while providing full fidelity sound. The Control 25AV can be used full range or low frequencies can be further augmented with the addition of one of the Control Contractor subwoofer models.
Frequency Range (-10 dB)
70 Hz – 23 kHz
Midrange ( 1.5 dB typical)
130 Hz – 14 kHz
100 Hr Power Capacity
200 Watts Continuous Program Power ; 100 Watts Continuous Pink Noise
Nominal Coverage
100 x 100
Nominal Sensitivity
87 dB SPL 1W @ 1 m (3.3ft)
Maximum SPL @ 1m
113 dB continuous peak pink noise ; 107 dB continuous average pink noise ; 103 dB continuous average music or speech
Directivity Factor (Q)
4.9 averaged 500 Hz to 4 kHz
Directivity Index (DI)
6.9 dB averaged 500 Hz to 4 kHz
Nominal Impedance
8 ohms
Minimum Impedance
6.7 ohms at 230 Hz
Crossover Type
Second Order Lowpass Second Order Highpass Complex Optimization for Maximally Flat Response
Transformer Taps
170V = 60W 30W 15W 7.5W taps (Taps #4#3 #2 & #1) ; 100V = 60W 30W 15W taps (Taps #3 #2 & #1) ; Thru position = 8 ohms nominal
Low Frequency Transducer
130 mm (5.25 in) polypropylene-coated paper with WeatherEdge surround 25 mm (1 in) voicecoil on kapton former
High Frequency Transducer
20 mm (.75 in) titanium coated PEI
Included Accessories
1 Pr MTC-PC input panel cover InvisiBall mounting base 6 mm x 100 mm InvisiBall hex wrench
Optional Accessories
MTC-25V for vertical columnar mounting of up to 3 speakers ; MTC-25/23H for horizontal splaying of 2 speakers. Three brackets array either 3 or 6 speakers in a hanging array module for 360 horizontal coverage. ; MTC-28/25CM to install speaker down from the ceiling. Check JBL Control Contractor Bracket and Adapter Handbook. ; MTC-xxWMG WeatherMax Stainless Steel Grille with a three-layer backing including vapor barrier to break up driving precipitation. Available in black or white (-WH).
Dimensions (H x W x D) : 236 x 186 x 159 mm (9.3 x 7.4 x 6.3 in)
Net Weight (ea) : 4.0 kg (9 lbs)
Shipping Weight (pair) : 9.0 kg (20 lbs) per pair
